Main Features
High strength steel shell, high-tension shackle and hook.
Excellent capability in resisting electromagnetic disturbance,
can applied directly to electromagnetic chuck.
0CS-D6H can be used under high temperature environment, the proper distance
between the scale and the hoist hot object: 1400℃ — 1.8m , 1600℃ — 2.0m
Main Dimensions
| Exterior Dimension of OCS-H6 |
| Capacity(t) |
Division(kg) |
Length |
Ring radia |
Rind heigh |
lifting hook |
Round shell height |
Diameter |
Weight (kg) |
| 1 |
1 |
560 |
95 |
58 |
25 |
140 |
265 |
43 |
| 2 |
1 |
560 |
95 |
58 |
25 |
140 |
265 |
43 |
| 3 |
1 |
560 |
95 |
58 |
25 |
140 |
265 |
43 |
| 5 |
2 |
820 |
120 |
80 |
45 |
190 |
265 |
45 |
| 10 |
5 |
940 |
125 |
90 |
55 |
190 |
265 |
53 |
| 15 |
5 |
1000 |
135 |
98 |
60 |
190 |
320 |
77 |
| 20 |
10 |
1100 |
235 |
127 |
75 |
190 |
320 |
96 |
| 30 |
10 |
1290 |
280 |
90 |
90 |
190 |
375 |
147 |
| 50 |
20 |
1645 |
290 |
160 |
160 |
296 |
510 |
360 |
